1-3W SMD LED Diode Bridgelux Chip
lSiab Luminous flux mus txog 200lm/w
lEMC lossis PCT Base muaj rau 1-3watt xav tau lub zog.
lSiv Asmeskas Bridgelux23x45mil lossis 26x30mil siab rau hauv cov nti.
lLub teb chaws Yelemees Heraeus 99.99% ntshiab Kub sib txuas hlau
lKev xaiv ntau yam rau Ra70, Ra80, Ra90, Ra95
lDC Voltage qauv 2.8-3.0V lossis 5.6-5.8V muaj.
lNyiam rau qib high-end high efficiency street teeb.
Khoom Qhia |
Parameter | Cim | Ntsuas | Chav nyob |
DC Mus Ntxiv Tam Sim No | IF | 200 | m A |
PeakpulseCurrent* | IFP | 250 | m A |
Rov Qab Tam Sim No | IR | 10 | μA |
Kev Ua Haujlwm Kub Ntau Yam | TOPR | -30 ~ +75 | °C |
Cia Kub Ntau Yam | TSTG | -40 ~ +85 | °C |
LED hlws ris Kub | TJ | 120 | °C |
Daim Ntawv Thov Khoom: |
GMKJ SMD 3030 LEDs feem ntau yog siv rau tus nqi muaj txiaj ntsig zoo teeb pom kev zoo txoj kev teeb pom kev zoo, lub teeb ci siab, cov khoom siv teeb pom kev zoo. Nrog cov LED no, qhov ua haujlwm siab tshaj plaws ntawm koj lub teeb ua tiav tuaj yeem ua tiav siab txog 180lm/w.
Txog Peb Lub Tuam Txhab: |
Peb lub tuam txhab yog lub tuam txhab thev naus laus zis siab hauv nroog Shenzhen. Cov khoom tseem ceeb suav nrog kev txhim kho txuas ntxiv thiab qhia txog cov khoom lag luam tshiab thiab thev naus laus zis, thiab cov khoom lag luam tau txuas ntxiv tsis tu ncua, feem ntau suav nrog cov hauv qab no: qhov ci ci LED, suav nrog liab, txiv kab ntxwv, daj, ntsuab, xiav, dawb, ntshav, infrared, ob-xim, thiab lwm yam; thaj (SMD) LEDs, suav nrog 3528, 3020, 5050, 5730, 5630, 3535, 5074, 3014, 2016, thiab lwm yam.
Xav paub ntau ntxiv txog peb, pls xa tuaj rau pebhais tawm. Nrhiav rau pem hauv ntej kom ua haujlwm nrog koj sai sai no!
