2835 liab coj 0.5w 620nm
● Ua los ntawm Original Sanan chips.
● Qhov Loj (L x W x H) hauv mm: 2.8x3.5mm
● Lub teb chaws Yelemees Heraeus Kub hlau
● Pom Lub Kaum (2θ1 / 2): Raug 120 °
Economy LEDs qhov chaw rau LED Bar
Kev Lag Luam LED rau kev coj cov hlua liab.
● Tsawg lub teeb attenuation tsawg dua 3% dhau 10000hrs.
EN62471, LM80, Rohs Pom Zoo
Product Dimension
Product Specification
Kev Rho Tawm Qhov Ntau Tshaj Plaws (Ntawm TA=25 ℃)
Tsis | Lub Cim | Kev Ntsuas | Chav Nyob |
DC rau Tam Sim No | IF | 150 | m A |
Peak mem tes Tam sim no * | IFP | 300 | m A |
Faiv Ntaj | PD | 0.5 | W |
Rov Qab Voltage | VR | 5 | V |
Ntxiag Tam Sim No | IR | 10 | μ A |
Kev Saib Xyuas Kev Ua Haujlwm Kub | TOPR | -30 ~ +75 | °C |
Cia Khoom Kub Ntau Yam | TSTG | -40 ~ +85 | °C |
LED hlws ris kub | TJ | 120 | °C |
Cov Hluav Taws Xob / Hluav Taws Xob Kho qhov muag - Dawb (Ntawm TA=25 ° C)
Tsis | Lub Cim | Cov xwm txheej | Min | Avg. | Max | Chav Nyob |
Kev Hloov Mus Tom Hluav Taws Xob | VF | IF= 150mA | 1.80 | -- | 2.40 | V |
Thermal Kuj Sib Tw Rau Pawg | RΘJ-B | IF= 150mA | -- | 8 | -- | °C/W |
Radiant Flux | Φe | IF= 150mA | 14 | 16 | lm | |
Ncov wavelength | λp | IF= 150mA | 625 | 630 | nm | |
Kub Coefficient ntawm Kev Kub Ua Ntej | ∆VF/∆T | IF= 150mA | −− | -2 | −− | mV / ° C |
Ntxiag Tam Sim No | IR | VR=10V | −− | −− | 10 | μ A |
Saib Lub Kaum [1] | 2Θ1/2 | IF= 150mA | −− | 120 | −− | Deg |
Daim Ntawv Thov Khoom
Light Teeb lub tsheb
● LED TXWV
Decoration Teeb lub teeb dai kom zoo nkauj
● Cov Teeb Tsav Tsheb LED
![]DN8[HSEEE60NRS9PPP)3J0](/Content/uploads/2020730013/202012161715373d68f061da6d4ddf95ef95ef4e2876e7.jpg)
Lwm qhov SMD LED kub muag
2020GM COG COJ HLOOV LUB TEEB SMD LED | ||||
TSWV YIM | QAUV | (PPE) μmol / J | IF / VF (V) | nti loj |
2835/3030 / K2 / 3535 Pkant hlob lub teeb Ib qho xim ntsuab xwb | ||||
1 | 2835Blue 450nm 0.2W | 1.8-2.0 | 60mA / 2.9-3.2 | Jucan 12 * 29 |
2 | 2835Red 620nm 0.2W | 1.4-1.8 | 60mA / 2.0-2.4 | Sanan 12 * 12 |
3 | 2835Red 660nm 0.2W | 2.2-2.4 | 60mA / 2.0-2.4 | Sanan 14 * 14 |
4 | 2835Red 740nm 0.2W | 50mW | 60mA / 19.0-2.3 | Epileds 14 * 14 |
5 | 2835Blue 450nm 0.5W | 2.0-2.2 | 150mA / 3.0-3.2 | tsab ntawv 17 * 34 |
6 | 2835Red 620nm 0.5W | 1.7-2.0 | 150mA / 2.0-2.4 | Epileds 20 * 20 |
7 | 2835Red 660nm 0.5W | 2.1-2.3 | 150mA / 1.9-2.3 | Epileds 20 * 20 |
8 | 2835Red 740nm 0.5W | 100mW | 150mA / 2.0-2.2 | Sanan 20 * 20 |
9 | 2835Blue 450nm 1W | 2.0-2.3 | 350mA / 2.8-3.0 | HUACAN 22 * 38 * 2 |
10 | 2835Red 620nm 1W | 2.0-2.3 | 350mA / 2.0-2.4 | Epileds 42 * 42 |
11 | 2835Red 660nm 1W | 2.1-2.3 | 350mA / 2.0-2.4 | Epileds 42 * 42 |
12 | 2835Red 740nm 1W | 300mW | 350mA / 1.6-2.0 | Sanan 42 * 42 |
13 | Lub zog loj LED xiav 450nm 1W | SIAB HWJ HUAM LED THIAB SMD3535 LED PACKAGE Style kuj tseem muaj rau cog cog teeb | ||
14 | Lub hwj chim loj LED Liab 620nm 1W | |||
15 | Lub zog loj LED Liab 660nm 1W | |||
16 | Lub hwj chim loj LED Liab 740nm 1W | |||
17 | EMC3030 Xiav 450nm 1W | 1.7-2.2 | 350mA / 2.9-3.2 | Epileds 45mil |
18 | EMC3030 Liab 620nm 1W | 1.8-2.3 | 350mA / 2.0-2.4 | Epileds 42 * 42 |
19 | EMC3030 Liab 660nm 1W | 1.9-2.3 | 350mA / 2.0-2.4 | Epileds 42 * 42 |
20 | EMC3030 Liab 740nm 1W | 300mW | 350mA / 1.6-2.0 | Sanan 42 * 42 |
25 | 2835 DAWB high PPE | 2.9-3.1 | 60mA / 2.7-3.0 | Huacan 22 * 38 * 2 |
26 | 3030 DAWB High PPE | 2.8-3.0 | 60mA / 2.7-3.0 | Hucan 22 * 38 * 2 |
27 | Tag Nrho Spectrum 2835 (RA95-98） | GS-3526W6-JC1734 | 0.2-0.3w | Jucan1734, cct6500k / 4000k / 3000k, 23-25lm |
28 | Tag Nrho Spectrum 2835 (RA95-98） | GS-3526W6-JC1530 | 0.2-0.3w | Jucan1530 ， cct6500k / 4000k / 3000k, 22-24lm |
29 | Tag Nrho Spectrum 2835 (RA95-98） | GS-3526W6-JC1229 | 0.2w | Jucan1229 ， cct6500k / 4000k / 3000k, 21-23lm |
Cov Txheej Txheem Xa Khoom
Lub sijhawm tus me nyuam:
● Kev txiav txim Qty< 10000pcs,="" 3-5="" hnub="" ua="">
● Kev txiav txim Qty> 10000pcs, 7-12 hnub ua haujlwm.
● Kev txiav txim Qty> 50000pcs, 12-20 hnub ua haujlwm.
Cov Khoom Siv Raw:
Lwm Yam Khoom muag kub
Tus khub ua lag luam
Tuam TxhabIb puag ncig
Shenzhen Guangmai Electronics Co., Ltd. yog lub tuam txhab High-Tech uas tau tsim nyob rau xyoo 2005, nrog lub hom phiaj yuav tsum tau lees paub tias yog lub ntiaj teb-qib High Power LED chaw tsim tshuaj paus thiab kev koom ua ke High Power LED daws cov chaw muab kev pab hauv China.Qhov zoo: Peb tuaj yeem ua ntawd lub teeb dawb yog xoom lub teeb tsis ua haujlwm hauv 20000 teev.
Nrog 10 xyoo ntawm kev txhim kho, peb lub tuam txhab tau nce mus rau lub npe nrov hauv kev lag luam teeb pom kev zoo thaum muaj xwm ceev. Peb lub tuam txhab cov neeg ua haujlwm 300 tus neeg ua haujlwm, nrog rau kev hloov txhua xyoo ntawm 100 lab RMB. Peb muaj ntau tus neeg ua haujlwm tau zoo nrog cov thev naus laus zis kom ua tau raws li cov qauv ntawm cov kev xav tau thoob ntiaj teb (ISO9001, IEC60825, ROHS, REACH).
Peb lub chaw tswj khoom zoo yog lub luag haujlwm los tshawb xyuas cov khoom tuaj, kev teeb tsa cov txheej txheem ua tau zoo los muab cov lus qhia ntxov ntawm kev ua haujlwm lossis lwm yam teeb meem, thiab ua qhov kawg tshawb xyuas thiab ntsuas cov khoom tiav. Nrog peb cov R& uas twb muaj lawm; D kom zoo dua, cov cuab yeej siv qib siab, pab pawg tswj hwm zoo tshaj plaws thiab cov kws tshaj lij, peb mob siab cia siab tias peb tuaj yeem koom tes nrog koj, thiab koj yuav muaj qhov tsim nyog thiab xis taug kev yog tias koj tuaj xyuas peb lub tuam txhab.
Q& A
Q: Koj cov khoom lag luam ntau npaum li cas?
A: Peb cov khoom tseem ceeb suav nrog:
· COB LED 2-400W
Compact SMD dawb / RGB / UV, IR LED 0.06W-5W
· Kev sib xyaw ua ke Flip Chip LED Module 3-500W
· Lub Zog Loj Zog LED 1-5W
· RGB LED lossis RGB / RGBW LED 1-100W
Q: Hom wavelength twg koj muaj?
Tam sim no peb muaj qhov pib ntawm txhua lub yoj yoj xws li:
UVC: 265-280nm
UVB: 300-320nm
UVA: 365-370nm, 395-405nm
LIAB: 620-630nm, 650-660nm
GREEN: 520-530nm
XIAV: 450-460nm; 460-470nm
AMBER: 590-595nm; 600-605nm
INFRARED: 730-740nm, 850-860nm, 930-940nm
Q: Koj puas muab cov qauv dawb?
A: Yog, Peb yuav muab cov qauv dawb rau P02 LED (1W siab zog LED, 6 koob 3W RGB LED), 3030 SMD LED, 5050 SMD LED, 3535 RGB LED, 3535 RGBW LED, thiab lwm yam.
Q: Koj puas yog cov chaw tsim khoom lossis chaw lag luam?
A: Peb yog cov chaw tsim khoom thiab cov kws tshaj lij LED txij thaum 2005.
Q: Koj txoj kev them nyiaj dab tsi koj txais?
A: Peb lees txais T / T, Paypal, Western Union thiab lwm yam ntxiv raws li cov neeg yuav tsum tau muaj.
Q: Ua li cas txog lub sijhawm ua hmoov txhuas?
A: Nws nyob ntawm kev txiav txim qhov ntau. Feem ntau, lub sijhawm ua hmoov txhuas yog li 5-7 hnub ua haujlwm. Rau cov qauv, cov khoom xa tuaj yeem ua ceev ceev ib hnub.
Q: Kuv tuaj yeem tau txais cov lus hais los ntawm koj li cas?
A: Thov ua siab zoo cia peb cov lus hais txog koj qhov kev xav tau, suav nrog cov khoom thiab ntau, peb pawg kws tshaj lij yuav teb koj sai (feem ntau li ntawm ob peb teev).
Q: Kuv tuaj yeem tau txais kev pab dab tsi tom qab kev yuav khoom?
A: Cov ntaub ntawv cov ntaub ntawv thiab kev ua haujlwm phau ntawv yuav muab rau koj tus hlub. Peb cov kws muag muag
Q: Dab tsi yog qhov ua tau zoo tshaj plaws ntawm koj smd coj.
A: Rau SMD5050 LED, kev ua haujlwm siab tshaj plaws yog 220lm / w.
Rau SMD3030 LED, qhov ua tau zoo tshaj yog 200lm / w.
Rau SMD2835 LED, qhov ua tau zoo tshaj yog 195lm / w
Q: Koj puas yog cov chaw tsim khoom lossis chaw lag luam? Muaj pes tsawg xyoo dhau los u muaj nyob rau hauv qhov kev lag luam.
A: Peb yog cov kws tshaj lij LED Ntim Hoobkas nrog ntau dua 4000㎡ ntau lawm hauv nroog Shenzhen, Suav. Txij xyoo 2008, peb qhib lub Hoobkas thiab ua peb lub npe GMKJ ua TOP100 LED kev lag luam txij xyoo 2010. koj zoo siab tos txais koj tuaj xyuas peb rau kev sib tham ua lag luam lossis npaj tawm rooj sab nraud los kuaj.
Q: Koj txoj kev them nyiaj dab tsi koj txais?
A: Peb lees txais T / T, Paypal, Western Union thiab lwm yam ntxiv raws li cov neeg yuav tsum tau muaj.
Q: dab tsi yog koj li lag luam. yam khoom twg yog muag kub tshaj plaws hauv koj lub tuam txhab.
A: Txoj cai tam sim no peb muaj li ntawm 60% kev lag luam nyob hauv Suav teb Main.Gov 40% ntawm kev lag luam oversea feem ntau yog los ntawm Cov Tebchaws xws li Asmeskas, Fabkis. Russia, Poland, Argentina. Is Nrias teb Qaib Cov Txwv thiab qee lub tebchaws nruab nrab sab hnub tuaj.
Tam sim no cov khoom kub muag khoom tau ua haujlwm siab SMD coj, xws li SMD5050 LED, SMD3030 LED, thiab SMD3535 LED hauv cov xim dawb thiab lwm yam xim xws li uv, ir, rgb.
Dhau li ntawm qhov no, cob coj daim ntawv 10-100watt kuj zoo siab txais tos los ntawm peb cov neeg siv khoom qub.
Peb tau zoo:3030 SMD LED
Cov qauv pub dawb yog cov khoom tsim nyog, 3 xyoo lav lub sijhawm.
Cov kab ntau lawm los lav zoo zoo.
Muaj tus kheej cov LED tshwj xeeb plua plav-dawb, tawm tsam kev ua haujlwm zoo li qub.
Ua rau ntau lub ntiaj teb-tebchaws United States ASM tsis siv neeg tshuab crystalline khoom,
ASM automatic soldering tshuab, H120 automatic LED lub teeb xim scanner kom paub tseeb tias qhov zoo.
