Guangmai Technology yog cov kws tshaj lij hauv kev ua theOsram Chip LED 1 - 3W SMD LED nrog 150LM / W.
Khoom nta
1. Tsawg - lub zog noj
2. Mus txog 80% txuag hluav taws xob
3.Zoo meej lub teeb faib nyhuv
4. Lub neej ua haujlwm ntev
5. Lub sijhawm teb luv luv
6. Muaj peev xwm tiv taus zoo
7.Pure 99.99% kub hlau bonding
8. Yooj yim rau nruab thiab siv
Peb Qhov Zoo
1.Txoj kev cog qoob loo& Teeb pom kev zoo theem.
2.Zoo - paub nti khoom, EPILEDS, BRIDGELUX, EPISTAR.
3.High flux ib LED Kev lag luam zoo tshaj noo noo rhiab heev.
4.Kaum xyoo dhau los tsim, RD, kev tsim hluav taws xob siab zog coj teeb Source.
5.RoHS, CE, FCC raws
6.A Tag Nrho Cov Xim Xaiv 360 txog 850nm.
7.Double Attach Method, Muaj peev xwm tiv thaiv kev poob siab tam sim no
Tam sim no peb tab tom siv Osram chips ODB4040UX3 series crystals los ntim 3535 smd leds nrog pob ceramic.
Cov crystals loj yog 40 * 40mil Osram hom. Nws tuaj yeem dais max 1000 mA nrog ib ncig ntawm 3.5 Watt.
Nws yog hom ntsug nti rau qhov pom kev zoo dua. Ntau tus neeg siv nws rau lub teeb ci LED lossis lub teeb ci coj los ua kom lub teeb tua ntxiv nrog lub teeb pom kev me me lub kaum sab xis lossis lub lens.
Osram thawj tsab ntawv rau Guangmai:
| GT - 3535 - FLIP35 - 1W | 1 - 2W | dawb 2700 - 6500k | Longda | 35 * 35 hli | 3 - 3.4VDC | 300 - 600mA | 140 - 150 LM |
| GT - 3535 - FLIP43 - 3W | 1 - 3W | dawb 2700 - 6500k | Longda | 43 * 43 hli | 3 - 3.6VDC | 300 - 800mA | 150 - 160 LM |
| GT - 3535 - FLIP55 - 4W | 1 - 4W | dawb 2700 - 6500k | Longda | 55 * 55 hli FLIP | 3 - 3.6VDC | 300 - 1200mA | 170 - 180 LM |
| GT - 3535 - FLIP55 - 5W | 1 - 5W | dawb 2700 - 6500k | Sanan | 55 * 55 hli FLIP | 3 - 3.6VDC | 1500 mA | 400 - 600 LM |
| GT - 3535 - OSR30 | 1 - 2W | dawb 2700 - 6500k | Osram | 30 * 30 hli | 3 - 3.6VDC | 300 - 600mA | 140 - 150 LM |
| GT - 3535 - OSR40 | 1 - 4W | dawb 2700 - 6500k | Osram | 40 * 40 hli | 3 - 3.6VDC | 300 - 1000mA | 155 - 170 LM |
| GT - 3535R - G42 | 1 - 3W | RED 620 - 630nm | Epiles | 42 * 42 hli | 2 - 2.4VDC | 300 - 700mA | 40 - 60 LM |
| GT - 3535R - G42 - 660 | 1 - 3W | Sib sib zog nqus liab 650 - 660nm | Epiles | 42 * 42 hli | 2 - 2.4VDC | 300 - 700mA | 30 - 50 LM |
| GT - 3535G - G45 | 1 - 3W | Ntsuab 520 - 530nm | Epiles | 45 * 45 hli | 3 - 3.4VDC | 300 - 700mA | 80 - 120 LM |
| GT - 3535B - G45 | 1 - 3W | Xiav 455 - 465nm | Epiles | 45 * 45 hli | 3 - 3.4VDC | 300 - 700mA | 20 - 30 LM |
| GT - 3535Y - J42 | 1 - 3W | Daj 585 - 595nm | Epistar | 42 * 42 hli | 2 - 2.4VDC | 300 - 700mA | 30 - 50 LM |
Osram Chip LED 1 - 3W SMD LED nrog 150LM / Wpob loj:
Osram Chip LED 1 - 3W SMD LED nrog 150LM / Wapplication
Hais txog Guangmai LED / GMKJ LED
GMKJ LED tuav ISO9001: 2000 qhov system zoo, txhua yam khoom tau ua raws li UL TUV SGS, CE, RoHS, LM - 79, LM - 80, EN62471.
Vim li cas thiaj xaiv GMKJ LED?
1. Zoo - paub nti khoom
2. 99.99% kub hlau bonding
3.2 xyoo warranty
4. Ntau tshaj 10 xyoo kev ua haujlwm pab pawg ua haujlwm
5. 24 teev kev pab cuam Kev muag khoom pab neeg
6. Cov qauv pub dawb muaj
7. Kev xa khoom sai
8.100% ib QC tshuaj xyuas ua ntej Shipping
9. Aiming ntawm kev sab laj ntawm" zoo, xoom tsis xws luag", muab koj qhov zoo tshaj plaws, kev pabcuam zoo tshaj plaws.
Daim ntawv qhia:
Yog xav paub ntxiv, thov hu rau Guangmai Tech ncaj qha.
Koj tuaj yeem download tau lubEnglish Version datasheetntawm Osram Chip LED 1 - 3W SMD LED nrog 150LM / W ntawm lub taub hau ntawm nplooj ntawv no.
