Guangmai Technology yog cov kws tshaj lij hauv kev ua rau 640-660nm 1w sib sib zog nqus liab siab zog coj teeb pom kev zoo.
Nta:
PLCC -2 packing
High-power LED hom
dej ntshiab packing
Qhov taw qhia kho qhov muag
Qhov rai tsis muaj xim
Zoo tagnrho rau backlight thiab lub teeb yeeb nkab daim ntawv thov
Inter reflector
Kev pom dav dav
Lub neej ua haujlwm ntev heev
Lub teeb tam sim (tsawg dua 100ns)
Lub teeb nyeem ntawv (tsheb, tsheb npav, dav hlau)
Mini accent/up-lighters/down lighters/orientation
Bollards / kev ruaj ntseg / vaj
Cov / hauv qab txee / ua haujlwm
Automotive rear vaj huam sib luag teeb
Sab hauv / sab nraum zoov coj mus muag thiab vaj tsev nyob
Edge teeb qhia (tawm, taw tes)
LCD backlights / teeb qhia
Tsim los rau kev ua haujlwm siab tam sim no
Tsawg thermal-resistance
Haum rau cov khoom siv tsis siv neeg tso
Haum rau vapor-theem reflow, infrared reflow thiab yoj solder txheej txheem
Cov khoom nws tus kheej yuav nyob hauv RoHS Cov Lus Qhia-raws li version
Nqe lus piav qhia:
High power series muaj nyob rau hauv mos liab, txiv kab ntxwv, daj, ntsuab, xiav thiab dawb
Vim lub ntim tsim, LED muaj lub kaum sab xis pom dav thiab optimized lub teeb coupling los ntawm inter reflector
Qhov no feature ua rau SMT sab saum toj LED zoo tagnrho rau lub teeb yeeb nkab daim ntawv thov
Cov kev xav tau qis tam sim no ua rau cov cuab yeej no zoo tagnrho rau cov khoom siv nqa tau yooj yim lossis lwm daim ntawv thov uas lub hwj chim yog tus nqi
Peb LED loj hlob lub teeb yog tag nrho spectrum, los ntawm 380-840nm
640-660nm 1w sib sib zog nqus liab siab zog coj loj hlob lub teeb specifications:
Nco tseg:
1, Tag nrho qhov ntev yog nyob rau hauv millimeters.
2, Kev kam rau siab yog ±0.1mm tshwj tsis yog sau tseg.
■ Cov yam ntxwv hluav taws xob / kho qhov muag --Dawb (ntawm TA=25 degree )
Parameter | Cim | Min | Avg. | Max | Chav tsev | Kev Xeem |
Forward Voltage | VF | 2.40 | -- | 2.80 | V | IF=700mA |
Thermal Resistance Junction Rau Board | RΘJ-B | -- | 8 | -- | degree / W | IF=700mA |
Luminous Flux | Φv | 40 | -- | 60 | ib lm | IF=700mA |
Dominant wavelength | λd | 650 | -- | 660 | nm | IF=700mA |
Kub Coefficient ntawm Forward Voltage | ∆VF/∆T | −− | -2 | −− | mV / degree | IF=700mA |
Rov qab tam sim no | IR | −− | −− | 10 | μ A | VR=5V |
Saib lub kaum sab xis [1] | 2Θ1/2 | −− | 140 | −− | Deg | IF=700mA |
Ntim Cov Lus Qhia
50 pcs / thawv
50pcs / tub
640-660nm 1w sib sib zog nqus liab siab zog coj loj hlob teeb daim ntaub ntawv:
Kev ua haujlwm ntawm Horticultural
Kev lag luam zaub thiab paj ntau lawm
Ntxiv rau tsev cog khoom teeb pom kev zoo
Hydroponics
Kev tshawb nrhiav kev sim
Hais txog GMKJ LED
Main Export Markets:
Asia / Australia Central / South America / Eastern Europe / Mid East / Africa
Shipping txoj kev
1-3 hnub rau cov qauv, 7-15 hnub rau kev txiav txim raws li qhov ntau.
tuaj yeem xa los ntawm hiav txwv, huab cua thiab nthuav qhia.
Txoj kev them nyiaj:
T / T (Lub txhab nyiaj hloov pauv), Western Union, Paypal, thiab lwm yam
Nrog ntau tshaj 12 xyoo kev paub hauv daim teb no,
peb ntseeg tias peb tuaj yeem dhau los ua koj tus neeg muag khoom txhim khu kev qha!
Txais tos kom nug.
Cov ntaub ntawv:
Yog xav paub ntxiv, thov hu rau Guangmai Tech ncaj qha.
Koj tuaj yeem download tau lubEnglish Version datasheetntawm640-660nm 1w sib sib zog nqus liab siab zog coj loj hlob teeblos ntawm lub taub hau ntawm nplooj ntawv no.
