Khoom Nta:
Kev Teeb Pom Kev Zoo txog li 160LM/W +
Chips yog tsim los ntawm Asmeskas Bridgelux
Xim Dawb 6000K los nrog CRI80-90
Tsawg Lub Teeb Tsawg tsawg dua 3% tom qab 6000hrs
IEC62778, EN62471, RoHS, LM-80 daim ntawv pov thawj pom zoo
Parameter | Cim | Ntsuas | Chav nyob | ||
Lub Hwj Chim Tawm | PD | 1W | 3W | W | |
DC Forward Voltage | VF | 3.0-3.4V | 3.2-3.6V | V | |
Qhia | DC Mus Ntxiv Tam Sim No | YOG | 350 mA ua | 700mA ua | mA |
Kev Ua Haujlwm Kub Ntau Yam | TOPR | -30 ~ +75 °C | °C | ||
Cia Kub Ntau Yam | TSSTG | -40 ~ +85 °C | °C | ||
LED hlws ris Kub | TJ | 125 °C | °C | ||
Electrostatic Txwv | ESD | 2000 V | V | ||
Kev Tiv Thaiv Cov Hluav Taws Xob Rau Lub Rooj Tsav Xwm | RΘJ-B | 8 °C/W | °C/W | ||
Cov yam ntxwv kho qhov muag (AT TA=25 ℃) | Xim Kub | CCT | 6000-6500 | K | |
Luminous Flux | Φv | GP-1W-J33 | GP-3W-P2345-2 | Tshooj No. | |
120-140 hli | 240-280 hli | LM | |||
| Chip Hom | Taiwan Epistar 33*33 | Bridgelux 23*45mil*2 | hli | ||
Beam Lub | 2Θ1/2 | 140 | Kawm tiav | ||
Ntim Txuj | PS | 50 | PCS | ||
Cov Hwj Huam LEDs (Dawb thiab Ntau Yam Xim) Cov Lus Qhia Xaiv:
Golden Dawb: 1800-2000K, 2000-2200K, 2200-2400K (585-595nm)
Sov Dawb LED: 2400-2600K, 2600-2900K, 2900-3200K, 3000-3500K
Ntuj Dawb/Ntshiab Dawb LED: 4000-4500K 5000-5500K
Txias Dawb: 6000-6500K, 6500-7000K
Txias Dawb: 7000-9000K, 9000-15000K, 15000-25000K
UV LED/Violet LED: 360-370nm; 370-380nm; 380-390nm; 390-400nm;
400-410nm; 410-420nm; 420-430nm
Royal Blue LED: 440-450nm Bright Blue LED: 460-470nm
Cyan LED: 490-495nm
Turquoise/Traffic Green LED: 500-510nm Emerald Green LED: 520-530nm
LED daj: 585-595nm Amber/Txiv kab ntxwv LED: 595-610nm
Liab Liab LED: 620-630nm Deep Red LED: 640-660nm
Duab Duab
Pob Dimension
Daim ntawv thov
Txog GMKJ LED
Shenzhen Guangmai Electronics Co., Ltd (tseem hu ua GMKJ LED, tsim nyob rau xyoo 2009), lub hauv paus chaw haujlwm hauv Shenhzen, yog ib ntawm Tuam Tshoj' ua tus coj LED ntim khoom lag luam nrog kev paub ntau hauv LED Kev lag luam teeb pom kev zoo. GMKJ LED, muaj zog R& D txoj kev txhim kho thiab tsim khoom sib xyaw ua ke hauv tsev, yog cov kws tshaj lij thiab tsim khoom tshwj xeeb hauv COB LED 2-400W, Lub zog LEDs 1-100W, SMD LEDs, Xim LEDs 275-940nm thiab lwm yam, uas tau siv dav rau teeb pom kev zoo, cog qoob loo, studio teeb pom kev zoo, toj roob hauv pes& teeb pom kev zoo thiab theem teeb pom kev zoo.
Feem ntau ntawm peb cov khoom coj yog LM-80 kuaj thiab pom zoo, tseem nrog RoHS EN62471/IEC62471 thiab lwm yam). Peb tau txais kev tso cai rau ntau dua 100 patents ob qho tib si hauv kev tsim thiab thev naus laus zis. Nrog rau qhov zoo tshaj plaws, muaj ntau haiv neeg thiab ua tau zoo, tus nqi tsim nyog, thiab kev txaus siab tom qab muag kev pabcuam, txhua yam ntawm peb cov khoom ua raws li cov txheej txheem zoo thoob ntiaj teb thiab zoo siab tos txais hauv ntau qhov kev lag luam sib txawv thoob plaws ntiaj teb.
FAQ
Q: Koj qhov khoom lag luam yog dab tsi?
A: Peb cov khoom tseem ceeb suav nrog:
COB LED 2-400W
· Compact SMD LED 0.06W-5W
· Kev Sib Ntsib Sib Ntsib Chip LED Module 3-500W
· Hwj chim LED 1-5W
· RGB LED lossis RGB/RGBW LED 1-100W
Q: Ua li cas txog lub sijhawm ua hmoov txhuas?
A: Nws nyob ntawm qhov kev txiav txim kom muaj nuj nqis. Feem ntau, lub sijhawm ua haujlwm yog li 5-7 hnub ua haujlwm. Txog kev kuaj, kev xa khoom tuaj yeem nrawm dua tib hnub.
Q: Kuv tuaj yeem tau txais cov lus hais los ntawm koj li cas?
A: Thov ua siab zoo tso peb cov lus hais txog koj cov kev xav tau, suav nrog cov khoom lag luam thiab ntau, peb pab pawg tshaj lij yuav teb koj sai sai no
(feem ntau tsis pub dhau ob peb teev).
Q: Kuv tuaj yeem tau txais kev txhawb nqa dab tsi tom qab kev yuav khoom?
A: Cov ntaub ntawv thiab phau ntawv qhia kev ua haujlwm yuav muab rau koj tus hlub. Peb tus kws muag khoom muag yuav teb koj cov lus nug txhua lub sijhawm.
Q: Yog tias muaj LED tsis ua haujlwm, koj tuaj yeem txhawb nqa li cas?
A: Cov neeg siv khoom muab cov duab ntawm cov khoom tsis ua tiav lossis cov qauv tsis pom zoo, tus kws kho tsheb yuav tshuaj xyuas qhov ua tsis tiav thiab tshawb nrhiav
yog vim li cas. Yog tias qhov ua tsis tiav los ntawm cov khoom lag luam zoo, peb yuav them nyiaj nrog qhov hloov pauv tau!
